Falling film plate evaporator
Falling film plate evaporator: Each group consists of two plates of different forms. The material enters from the left and right openings at the top of the plate, and the steam-water mixture goes out from the large square opening in the middle of the bottom; the steam enters from the large opening in the middle of the top of the plate, and the condensed water goes out from the left and right openings at the bottom. The low-resistance corrugation is used to make the medium evenly distributed, with low resistance and high efficiency.
This falling film plate greatly improves the efficiency of the evaporation equipment to adapt to the concentration of large-volume, high-concentration, and high-viscosity materials.
Product Description
Detailed parameters
|
Model |
Single board area |
Overall dimensions A*B |
Corner hole diameter C(mm) |
Corner hole diameter D(mm) |
Corner hole diameter E(mm) |
Corner hole diameter F(mm) |
|
J150 |
0.25 |
985*430 |
Φ150 |
Φ32 |
Φ38 |
Φ150 |
|
J700 |
1.5 |
2380*1205 |
Φ600 |
Φ76 |
Φ100 |
Φ700 |
Advantages of plate evaporator
1. High efficiency
2. Small footprint/low infrastructure investment
3. Short material residence time
4. Small liquid holding volume
5. Easy installation and maintenance
6. Convenient inspection
7. Low equipment investment cost
ENCO Advantages
1,ENCO was established in 2003. We have more than 20 years of experience and specialize in the design and manufacture of Multiphase Evaporators, MVR Evaporators, Plate Heat Exchangers.
2.ENCO provides integrated solutions from in-house detailed design and engineering; manufacturing and modularization; installation and commissioning, as well as trainning and O&M services.
3,As we have successfully delivered complicated technical and equipment packages of more than 600 projects golbally to 30+countries including USA, UK, Australia, China, South Korea, Singapore and etc. Our in-house engineering team can design the system according to ASME,ASTM, Australian Standard(AS), British Standards Institute (BS) and other local standards and codes.
